Meet BASEPOINT™. A dedicated mounting position for your GNSS base today. A reusable mount for the next job.
PREVIEW A FINISH Black
Preview only. Message your color through eBay after purchase. Without a message before dispatch, the first available color ships.GNSS BASE STATION POST MOUNT
A fixed place for the base.
A mount that moves with the work.
Give your GNSS base a defined mounting position on a prepared post. BASEPOINT combines a secured threaded-fitting assembly, a 5/8″-11 receiver connection, and individual serial identification in one reusable mount.
After purchase, message us your color through eBay. Without a color message before dispatch, the first available color ships. This preview does not select your color on eBay.
In the box: BASEPOINT in your selected finish, the 5/8″-11 GNSS mounting stud/nut assembly, and four wooden-post mounting screws. Receiver, post, concrete and site installation are not included.
01 / THE DETAILS THAT MATTER
The front carries the product. The reverse identifies your mount. From setup to relocation, BASEPOINT keeps the hardware recognizable and the individual unit traceable.
Approximately eight inches of offset from the post to the GNSS mounting point, with a 5/8″-11 connection on a secured threaded-fitting assembly. Check receiver thread engagement, body clearance and connector access for your equipment before ordering.
Individual serial identification on the reverse keeps each mount identifiable. Record the serial with your order and job assignment; the QR code links back to ForgedOpsHQ.com.
YOUR HARDWARE. IDENTIFIED.
Product branding / Individual serial / ForgedOps QR link
02 / FINISH OPTIONS
Black. Lime green. Cherry red. Orange. White. Choose the look for your equipment, or ask about a custom color for your operation.
Color availability and lead time are confirmed when ordering. Screen and print colors may differ from the finished product.
03 / INSTALLATION & SETUP
A stable base begins with a sound post, a secure footing and a clear view of the sky. Install the mount around the needs of your site and your GNSS equipment.
Read the complete installation guide ↗Select stable ground outside traffic and active work areas. Maintain a clear sky view and confirm underground utilities before digging.
Use an 8-ft or longer ground-contact treated 4×4. Secure the footing with concrete, plumb two adjacent faces, brace and follow the concrete manufacturer’s curing instructions.
Use the four supplied mounting screws in a sound wooden post, securing every flange hole. Keep the arm level and the receiver stud vertical. Position the receiver and connectors clear of the post.
Set the base position and antenna height using your equipment procedures. Verify known control before work begins and record the mount’s serial number.
The brochure’s 18–24 in. embedment is a starting range, not a universal footing specification. Soil, wind and local conditions may require a deeper or larger footing.
04 / FIELD CARE & REUSE
Remove the receiver and cables, unfasten the flange, and inspect the mount before transfer. At the next prepared post, re-establish the base position, antenna height and control checks.
Check post stability, receiver seating, fasteners and secured connections. Verify known control.
Check both post faces with a level, inspect the footing for movement or rotation, and record the inspection.
Recheck after heavy rain, high winds or impact. Stop using a shifted setup until corrected and re-established.
PRODUCT RESOURCES
Product overview, finishes and installation essentials.
Open product sheet ↗02 / PDFProduct brochureProduct identification, setup, care, reuse and GNSS responsibilities.
Open brochure ↗BEFORE YOU ORDER
One BASEPOINT mount in your selected finish, the 5/8-inch-11 GNSS mounting stud/nut assembly, and four screws for a wooden post. Approximately eight inches of offset from the post to the GNSS mounting point. Receiver, post, concrete and site installation are not included.
BASEPOINT uses a 5/8-inch-11 GNSS connection. Check compatible thread engagement, receiver clearance and cable access for your specific model. Contact us with the make and model if you need help.
Yes. Remove the receiver and cables, remove the flange fasteners and inspect the assembly before transferring it to a prepared post. Re-establish the base position and antenna height and verify control at the new location.
Purchases are completed on eBay. Review shipping services, applicable tax and the final total there before paying. For six or more mounts, message us through eBay before purchasing.
Yes. Contact ForgedOps to discuss the finish, availability, lead time and any custom pricing before ordering.
PURCHASE WITH CLARITY
One-year limited warranty against manufacturing defects. Thirty-day returns on undamaged, like-new standard-color mounts with all included hardware.
Read the full shipping, return & warranty policies ↗Same-day shipping target for in-stock standard colors ordered before 3 p.m. Eastern on business days. Carrier transit begins after handoff—not when you place the order.
Custom colors are final sale for change-of-mind returns. Manufacturing-defect coverage remains; an exact replacement color is not guaranteed if unavailable.
EQUIP THE WHOLE CREW
Contact ForgedOps for bulk-order discounts and a shipping quote built around your order. Custom colors may also be available depending on quantity.
Request bulk pricing Or call 904-297-8419Tell us how many mounts you need, your preferred colors and delivery ZIP code. We’ll confirm pricing, shipping and timing with you.
BASEPOINT / AVAILABLE ON EBAY
Explore the hardware here. Complete your purchase on our eBay listing. Review availability, shipping options, applicable tax and your final total before paying.
YOUR NEXT BASE SETUP
Color preview: Black. Your selection here is a preview only and is not sent to eBay.
After purchasing, message us through eBay with the color you want. If we do not receive a color message before dispatch, we will ship the first available color.
Need a specific color? Confirm availability through eBay before buying.
Buy BASEPOINT on eBayYou will leave ForgedOps to complete your order. The eBay listing and checkout show current price, availability, delivery estimates and purchase terms.
Talk through your setup with ForgedOps. 904-297-8419 · info@forgedopshq.com
